The CMX EVAC-240RT is a professional 6-zone voice evacuation router with a built-in 240W Class-D amplifier, designed for life safety and emergency communication systems compliant with EN54-16 standards. Engineered for mission-critical applications, it provides reliable emergency voice broadcasting, intelligent zone control, and seamless integration with fire alarm systems.

The unit features 6 independent speaker zone outputs with individual volume control, allowing emergency messages and live announcements to be broadcast to selected zones or throughout the entire facility. It receives audio sources and emergency fire alarm messages directly from the master controller, ensuring fast and reliable emergency communication.

For enhanced system reliability, the EVAC-240RT incorporates A/B speaker line low-impedance supervision, continuously monitoring speaker circuits for faults. In the event of an amplifier failure, the system automatically switches to a standby amplifier, ensuring uninterrupted emergency operation. It also includes an extension amplifier connector for system expansion and supports both AC mains and DC battery operation, providing continuous functionality during power outages.

Certified to EN54-16, the CMX EVAC-240RT is ideal for airports, hospitals, hotels, shopping malls, office buildings, educational institutions, transportation hubs, factories, and other commercial or public facilities requiring dependable voice evacuation and emergency public address systems.

Key Features

• EN54-16 certified voice evacuation router
• Built-in 240W high-efficiency Class-D amplifier
• 6 independent speaker zone outputs
• Individual zone volume control
• Receives audio sources and fire alarm messages from master controller
• A/B speaker line low-impedance supervision
• Automatic amplifier changeover to standby during faults
• Extension amplifier connector for system expansion
• Supports emergency voice evacuation and public address
• AC mains and DC battery operation
• High speech intelligibility for emergency announcements
• Ideal for commercial and life safety applications
