Consumer IPC (Wi-Fi) (DS-2CV2Q21G1-IDW)
Consumer IPC (Wi-Fi) (DS-2CV2Q21G1-IDW) - Image 2
Consumer IPC (Wi-Fi) (DS-2CV2Q21G1-IDW) - Image 3
Consumer IPC (Wi-Fi) (DS-2CV2Q21G1-IDW) - Image 4
5 in stock

Consumer IPC (Wi-Fi) (DS-2CV2Q21G1-IDW)

SKU: DS-2CV2Q21G1-IDW (W) (4mm)
Category: , ,
Original price was: ₱3,855.60.Current price is: ₱1,239.70.

Model:DS-2CV2Q21G1-IDW (W)
Lens Type: (4mm)

  • Support Wi-Fi connection
  • Support Motion 2.0, human detection
  • Built-in microphone and speaker, support two-way audio
  • Mobile monitoring via mobile application
  • Support on-board storage, up to 512 GB
  • Clear imaging against strong back light due to DWDR technology
  • 3D DNR technology delivers clean and sharp images

5 in stock

  • Camera
  • Image Sensor1/3″ Progressive Scan CMOS
  • Max. Resolution1920 × 1080
  • Min. IlluminationColor: 0.05 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR
  • Shutter Time1/3 s to 1/100,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 330°, tilt: 0° to 60°, rotate: 0° to 360°
  • Lens
  • Focal Length & FOV4 mm, horizontal FOV 75°, vertical FOV 45°, diagonal FOV 85°
  • Lens MountM12
  • ApertureF2.0
  • Illuminator
  • Supplement Light TypeIR
  • Supplement Light RangeUp to 10 m
  • Video
  • Main Stream

    50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 × 432)

    60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 × 432)

  • Sub-Stream

    50 Hz: 25 fps (768 × 432, 512 × 288)

    60 Hz: 30 fps (768 × 432, 512 × 288)

  • Video Compression

    Main stream: H.265/H.264

    Sub-stream: H.265/H.264

  • Video Bit RateUp to 1 M bps
  • Frame Rate

    Max.15 fps

    Self-Adaptive during network transmission

  • Audio
  • Audio CompressionG.711/AAC-LC
  • Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate8 kHz/16 kHz
  • Environment Noise FilteringYes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS
  • Simultaneous Live ViewUp to 4 channels
  • APIONVIF (Profile S, Profile T, Profile G), SDK
  • User/HostAdministrator
  • SecurityPassword protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface
  • ClientiVMS-4200, Hik-Connect, Hik-Partner-Pro
  • Wi-Fi
  • Encryption ModeWPA-PSK/WPA2-PSK
  • Frequency Range2.412 GHz to 2.472 GHz
  • Channel Bandwidth20 MHz
  • Transfer Rate

    11b: up to 54 Mbps,

    11g: up to 54 Mbps,

    11n: up to 150 Mbps

  • Wireless RangeUp to 50 m (The performance varies based on actual environment)
  • Image
  • Image SettingsRotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software
  • Day/Night SwitchAuto
  • Wide Dynamic Range (WDR)Digital WDR
  • Privacy Mask4 programmable polygon privacy masks
  • Interface
  • Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
  • On-Board StorageBuilt-in memory card slot, support microSD card, up to 512 GB
  • Built-in MicrophoneYes,1 built-in microphone
  • Built-in SpeakerYes, 1 built-in speaker
  • Reset KeyYes
  • Event
  • Basic EventMotion detection (support alarm triggering by specified target type (human)), exception
  • General
  • MaterialPlastic
  • DimensionØ80 mm × 122 mm (Ø3.14″ × 4.8″)
  • Package Dimension105 mm × 105 mm × 190 mm (4.1″ × 4.1″ × 7.5″)
  • Approx. 216 g (0.48 lb.)
  • With Package WeightApprox. 554 g (1.22 lb.)
  • Storage Conditions-10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions-10 °C to 45°C (14 °F to 113 °F). Humidity 95% or less (non-condensing)
  • General FunctionHeartbeat,mirror
  • Power5 VDC ± 10%, 1 A, max. 5 W
  • Flashing LightRed and Blue Light
  • Approval
  • RFCE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G))
  • EMC

    CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014)

  • Safety

    CE-LVD: EN 62368-1: 2014/A11: 2017

  • Environment

    CE-RoHS: 2011/65/EU,

    WEEE: 2012/19/EU
