Key Specifications & Features

1. Resolution & Sensor

   • 2 MP (1920 × 1080) image resolution.

   • Uses a 1/2.8″ Progressive-Scan CMOS sensor.

2. Lens / Field of View (FOV)

   • Fixed focal length: 4 mm.

   • Field of View for 4 mm: ~86° horizontal, ~47° vertical, diagonal ~102°.

   • Lens mount: M12.

   • Aperture: F/1.4.

3. Illumination / Low-Light Performance

   • Very low minimum illumination: 0.002 Lux (color), 0 Lux in B/W with IR on.

   • Equipped with IR (infrared) supplementary light for night vision up to ~40 m.

   • IR wavelength: 850 nm.

4. Wide Dynamic Range & Image Enhancement

   • 120 dB True WDR (Wide Dynamic Range) for handling strong backlight / contrast.

   • Image enhancement features: BLC (Back Light Compensation), HLC (Highlight Compensation), 3D DNR (Digital Noise Reduction).

5. Compression & Streaming

   • Video compression: H.265, H.264, H.264+, H.265+, and MJPEG.

   • Multiple video streams supported (main, sub, third) for efficient transmission even on poor networks.

6. Smart / Deep Learning Features

   • AcuSense: can classify objects as human or vehicle to reduce false alarms.

     Supports perimeter protection: line crossing, intrusion detection, region entrance/exiting.

   • Face capture capability.

   • Event linkage: can trigger actions like upload to NAS, memory card, send email, trigger recording.

7. On-Board Storage

   • Has a microSD / SDHC / SDXC card slot, supporting up to 512 GB.

   • Supports ANR (Auto Network Replenishment) for smooth recording when network is unavailable.

8. Network / Interface

   • Network port: 1 × RJ45 (10/100 Mbps).

   • Protocols supported: TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, SSL/TLS, PPPoE, ARP, SNMP.

9. Power

   • Power options: 12 V DC (± 25%) or PoE (IEEE 802.3af).

   • Power consumption: max ~7 W (DC) / ~8.5 W (PoE).
     Durability / Build

   • IP67-rated: dust-tight and water-resistant.Operating temperature: about -30 °C to +60 °C.
     Operating humidity: < 95%.
     Mechanical / Adjustment

   • Angle adjustment: Pan 0°–360°, Tilt 0°–90°, Rotate 0°–360°.

   • “Day/Night” mode: IR-cut filter for switching between day and night.

10. Reliability / Alerts

    • False-alarm reduction using human/vehicle classification via deep learning.

    • Alarm I/O: 1 input, 1 output (max 12V DC, 30 mA).

11. General

    • Part of Hikvision’s “Ultra / SmartIP” series.

    • Compressed firmware and local storage support make it suitable for both edge-recording and network-based setups.

    • Reliable for outdoor use because of its rugged IP67 housing and good low-light performance.
