Switch (DS-3T0510HP-E/HS)

SKU: DS-3T0510HP-E/HS

8 Port Gigabit Unmanaged Harsh POE Switch

6 × gigabit PoE RJ45 port, 2 × gigabit Hi-PoE RJ45 port and 2 × gigabit SFP fiber optical port.
IEEE 802.3at/af/bt standard for Hi-PoE port (Max. 90 W PoE output).
IEEE 802.3at/af standard for PoE ports (Max. 30 W PoE output).
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab standard.
6 kV surge protection for PoE ports.
Up to 300 m long-range transmission.
PoE watchdog to auto detect and restart the cameras that do not respond.
Port isolation to improve network security.
Wire-speed forwarding.
Wider temperature (-30 °C to 65 °C) design.
Store-and-forward switching.
Solid high-strength metal shell.
Reliable fan-free design.

1 in stock

6 × Gigabit RJ45 PoE ports + 2 × Gigabit RJ45 Hi-PoE ports + 2 × Gigabit SFP fiber ports.

Hi-PoE ports support IEEE 802.3 af/at/bt, with up to 90 W per port.
Regular PoE ports support IEEE 802.3 af/at, up to 30 W per port.
Total PoE budget: 110 W.
Switching capacity: 20 Gb/s.
Packet forwarding rate: 14.88 Mpps.
Long-range data + power support: Ports 7–8 support up to 300 m transmission in long-range mode.
Port isolation mode (ports 1–8) for improved network security.
PoE-watchdog: automatically detect & restart connected cameras (or PoE devices) that are non-responsive.
- Operating temperature range: -30 °C to 65 °C (-22 °F to 149 °F).
- Storage temperature: -40 °C to 85 °C.
- Metal shell, fan-free design.
- Surge protection: 6 kV for PoE ports.
- Power supply: 54 V DC, 2.5 A. Maximum power consumption about 120 W.
  Net weight: ~0.585 kg; gross weight ~1.11 kg. Dimensions: 197 mm × 114.2 mm × 42.2 mm.
  - Designed for harsh environments (industrial settings) thanks to wide temperature range and metal fan-free enclosure.
  - Ideal for powering high-power PoE devices (e.g., PTZ cameras or other equipment needing up to 90 W) via the Hi-PoE ports.
  - Long-distance link ability on ports 7 & 8 supports installations where cable runs are extended (up to ~300 m).
  - Unmanaged switch (plug-and-play) simplifies deployment without need for complex configuration.

Attributes	Value
Weight	2 kg
Dimensions	2 × 3 × 2 cm
