HUAWEI Switch S220-24T4X

The Huawei S220-24T4X is a managed Layer 2 Gigabit Ethernet switch designed to meet the networking needs of small to medium-sized enterprises (SMEs). It offers a balance of performance, flexibility, and ease of use, making it suitable for various applications such as office networks, educational institutions, and commercial environments.

Key Specifications:

• Port Configuration:

  • Downlink Ports: 24× 10/100/1000BASE-T Ethernet ports
  • Uplink Ports: 4× 10 Gigabit SFP+ ports

• Performance:

  • Switching Capacity: 128 Gbps
  • Packet Forwarding Rate: 95 Mpps

• Physical and Environmental:

  • Dimensions (H × W × D): 43.6 mm × 442 mm × 220 mm
  • Weight: Approximately 2.32 kg
  • Operating Temperature: -5°C to 50°C
  • Storage Temperature: –40°C to +70°C
  • Operating Humidity: 5% to 95% (non-condensing)

• Power Specifications:

  • Power Supply: 100–240 V AC, 50/60 Hz
  • Maximum Power Consumption: 35.04 W
  • Typical Power Consumption: 27.27 W
