The Huawei S310-24P4S is a managed Gigabit Ethernet switch designed to provide high-performance network connectivity with Power over Ethernet (PoE) capabilities, making it suitable for small to medium-sized businesses and enterprise networks.

Key Specifications:

• Port Configuration:

  • 24 × 10/100/1000BASE-T Ethernet ports with PoE+ support
  • 4 × Gigabit SFP uplink ports

• PoE Capabilities:

  • Supports IEEE 802.3af/at standards
  • Provides up to 400 W total PoE power budget
  • Fast PoE and Perpetual PoE features ensure immediate and uninterrupted power supply to connected devices

• Performance:

  • Switching Capacity: 260 Gbps
  • Packet Forwarding Rate: 42 Mpps

• Physical Specifications:

  • Dimensions (H × W × D): 43.6 mm × 442.0 mm × 220.0 mm
  • Weight: Approximately 2.92 kg (excluding packaging)
  • Form Factor: 1U, suitable for rack mounting

• Power and Environmental:

  • Power Supply: Built-in AC power module
  • Input Voltage: 100 V AC to 240 V AC, 50/60 Hz
  • Maximum Power Consumption: 47.1 W (without PoE), up to 491.66 W with full PoE load
  • Operating Temperature: -5°C to +50°C
  • Operating Humidity: 5% to 95% (non-condensing)

• Features:

  • Supports various security protocols, including MAC address authentication and 802.1X authentication
  • Offers intelligent stacking (iStack) for simplified network management
  • Provides advanced QoS features for traffic prioritization
  • Managed through SNMP, CLI, web-based interface, or SSH
